Mispa Count Plus Automated 5-Part Diff Hematology Analyzer

Mispa Count Plus Automated 5-Part Diff Hematology Analyzer Overview

The Mispa Count Plus Automated 5-Part Diff Hematology Analyzer is a state-of-the-art, compact diagnostic instrument engineered to deliver precise and reliable blood cell counts. Leveraging cutting-edge German technology, this analyzer is designed to meet the rigorous quality demands of modern laboratories, offering efficient workflow management and exceptional accuracy for a 5-part differential analysis. It represents a cost-effective yet high-performance solution for laboratories seeking to enhance their diagnostic capabilities without compromising on quality.

Mispa Count Plus Automated 5-Part Diff Hematology Analyzer Key Features

• Advanced 5-Part Differential Analysis: Provides detailed differentiation of white blood cells, including histograms for RBC and PLT, and scatter plots for WBC, offering comprehensive insights.
• High Throughput: Efficiently processes up to 60 samples per hour, optimizing laboratory workflow and reducing turnaround times.
• User-Friendly Interface: Features an 8.4-inch LCD touchscreen with excellent contrast ratio for intuitive operation and easy navigation.
• Cutting-Edge Technology: Utilizes LED-based flow cytometry and triple counting technology to ensure consistently accurate and dependable results.
• Robust and Reliable: Built with sturdy hardware designed for minimal maintenance and sustained optimal workflow management.
• Cost-Effective Operation: Employs cyanide-free reagents, reducing operational costs and enhancing laboratory efficiency while maintaining high standards of quality.
• Large Data Storage: Capable of storing up to 35,000 results, including scatter plots, for easy data retrieval and analysis.
• Flexible Sampling: Supports both whole blood (15.6 µL) and pre-diluted (20 µL) sample modes.
• Versatile Connectivity: Equipped with 5 USB ports, RS 232, and Ethernet (RJ45) for seamless integration into laboratory networks.

Technical Specifications

• Brand: Agappe
• Differential Type: 5-Part
• Model Series: Mispa Count Plus
• Screen: 8.4-inch LCD touchscreen
• Throughput: 60 Samples/Hour
• Technology: LED (Light Emitting Diode) based flow cytometry, Triple counting technology
• Storage Capacity: 35,000 results with scatter plot
• Sampling Modes: Whole blood (15.6 µL) | Pre-diluted (20 µL)
• Aperture Size: 80 microns (WBC), 50 microns (RBC & PLT)
• Connectivity: 5 USB ports, RS 232, Ethernet – RJ45
• Reagents: Diluent D5, Cleaner C5, Lyse L5, Probe Cleaner P5
• Dimensions: 405 x 270 x 430 mm (Height x Width x Depth)
• Weight: 12 Kg
• Input Power: 100-200 V AC
• Output: 24V – 6.25 Amp
• Power Consumption: 160 Watt
• Working Temperature: 18-32 Degrees C
• Relative Humidity: Up to 80%
• Mode: Open Vial
