Celltus 40 Hole Automated ESR Analyzer

Celltus 40 Hole Automated ESR Analyzer: Precision Erythrocyte Sedimentation Rate Testing for Laboratories

The Celltus 40 Hole Automated ESR Analyzer is a state-of-the-art, benchtop laboratory instrument engineered for accurate and efficient Erythrocyte Sedimentation Rate (ESR) analysis. Utilizing the widely recognized Westergren method combined with advanced infrared sensor technology, this analyzer provides reliable diagnostic results. Its intuitive touchscreen interface and robust design make it an essential tool for modern clinical laboratories in Bangladesh seeking high-throughput and dependable ESR testing.

Celltus 40 Hole Automated ESR Analyzer: Key Features

• High Throughput Capacity: Analyzes up to 40 samples simultaneously, achieving a remarkable throughput of up to 80 samples per hour, significantly enhancing laboratory efficiency.
• Dual Measurement Time Options: Offers flexibility with selectable measurement times of 30 minutes or 60 minutes to accommodate different laboratory workflows and clinical demands.
• Intuitive Touchscreen Interface: Features a large, vibrant 7-inch color touchscreen display for easy operation, sample loading, and result review.
• Integrated Reporting: Equipped with a built-in thermal printer for immediate on-demand printing of ESR results and curves.
• Advanced Measurement Principle: Employs an infrared sensor measuring principle for precise and consistent detection of erythrocyte sedimentation.
• ESR Curve Display: Visually displays the ESR curve for each sample, aiding in interpretation and quality control.
• LIS Connectivity: Supports LIS (Laboratory Information System) connection for seamless integration into existing laboratory data management systems.
• Optional Barcode Reader: Enhances sample identification accuracy and streamlines workflow with an optional barcode reader.
• Robust Construction: Designed as a durable benchtop unit for reliable performance in demanding laboratory environments.

Technical Specifications

• Model: Celltus ESR-40
• Type: Automated ESR Analyzer
• Analysis Method: Westergren
• Measuring Principle: Infrared Sensor
• Sample Loading Capacity: 40 samples at the same time
• Throughput: Up to 80 samples per hour
• Reading Channels: 40
• Loading Pattern: Random
• Measurement Range: 1 to 140 mm/h
• Result Resolution: 1mm/1h, 1mm/2h
• Reading Resolution: ±0.1mm
• Blood Level Range: 50mm ~ 64mm
• Measurement Time: 30 minutes or 60 minutes (selectable)
• Sample Interval: 3 minutes
• Temperature Compensation: Automatic at 18°C (selectable)
• Data Storage: 4,000 results
• Display: 7-inch color touchscreen
• Printer: Internal thermal recorder
• Interface: RS-232 serial port
• Power Supply: AC 100-240V, 50-60Hz, 50W
• Operating Temperature: 5°C to 40°C
• Operating Humidity: ≤80%
• Dimensions (LxWxH): 365mm × 300mm × 180mm
• Net Weight: 8 Kg
