Transasia Hematology Analyzer – H 360 – Automatic 3-Part differential hematology analyzer

Transasia Hematology Analyzer – H 360 – Automatic 3-Part differential hematology analyzer Overview

The Transasia Hematology Analyzer – H 360 is a state-of-the-art automatic 3-part differential hematology analyzer, expertly engineered for precise Complete Blood Count (CBC) analysis. This advanced device is designed for high-throughput laboratories, offering reliable and accurate results essential for patient diagnosis and management.

Transasia Hematology Analyzer – H 360 – Automatic 3-Part differential hematology analyzer Key Features & Benefits

• Comprehensive Analysis: Reports on 22 parameters including P-LCC and P-LCR, ensuring thorough patient assessments.
• Eco-Friendly Testing: Utilizes cyanide-free reagents for hemoglobin tests, promoting safety and environmental consciousness.
• Efficient Sample Processing: Processes up to 60 samples per hour, enhancing laboratory productivity.
• Versatile Counting Modes: Supports whole blood, capillary, and pre-dilute modes, accommodating various sample types.
• Robust Data Management: Features a large storage capacity of 50,000 samples with real-time inventory management and bidirectional interfacing.
• User-Friendly Interface: Equipped with a 10.4-inch large colored LCD touch screen for easy navigation and operation.

Technical Specifications

• Mode Type: Whole Blood, Predilute, Capillary
• Total Parameters: 22 parameters including CBC, WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD, PLT, MPV, PCT, PDW-CV, PDW-SD, P-LCR, P-LCC
• Principle of Measurement: Electrical Impedance for cell counts; Cyanide-Free Colorimetry for hemoglobin
• Sample Volume: Whole Blood: 9 µL; Pre-diluted: 20 µL; Capillary: 20 µL
• Linearity Range: WBC: 0–300 (x 103/µL); RBC: 0.00–8.50 (x 106/µL); Hb: 0–25.0 (g/dL); HCT: 0–67 (%); PLT: 0–3000 (x 103/µL)
• Data Storage: 50,000 results with graphs and quality control files
• Dimensions: 364 x 477 x 417 mm
• Weight: 25 kg
• Power Requirement: AC 100-240V with built-in voltage stabilizer, 50/60Hz, 200VA
• Operating Environment: Temperature 15-40˚C; Humidity 30-90%
