DiaSYS Full Automatic Biochemistry Analyzer DIA-3300

DiaSYS Full Automatic Biochemistry Analyzer DIA-3300 Overview

The DiaSYS Full Automatic Biochemistry Analyzer DIA-3300 is a state-of-the-art, automated random-access clinical chemistry and turbidimetry analyzer engineered for high-volume diagnostic laboratories. This compact yet powerful instrument delivers exceptional accuracy and efficiency, making it an indispensable tool for comprehensive biochemical analysis in healthcare settings across Bangladesh. It is designed to streamline workflows and provide reliable results, supporting critical patient care decisions.

DiaSYS Full Automatic Biochemistry Analyzer DIA-3300 Key Features & Benefits

• High Throughput: Offers a minimum constant throughput of 400 tests/hour, expandable to 640 tests/hour with the optional ISE module, ensuring rapid processing of samples.
• Random Access Capability: Allows for STAT (emergency) sample analysis at any time, without interrupting routine testing, enhancing laboratory responsiveness.
• Versatile Sample Handling: Accommodates various sample types including Serum, Plasma, CSF, and Urine, with adjustable sample volume from 2-40 µl.
• Advanced Photometry: Features 8 wavelengths (340, 405, 450, 510, 546, 578, 630, and 670 nm) for both mono- and bichromatic measurements, ensuring precise photometric analysis.
• Integrated Ion Measurement: Includes photometric tests for essential electrolytes like Na+, K+, and Cl-, providing a comprehensive panel.
• Intelligent Sensors: Equipped with liquid level and crash sensors to prevent errors and protect the analyzer, ensuring operational safety and longevity.
• Flexible Calibration: Supports linear, non-linear, and multi-point calibration methods for accurate assay results.
• User-Friendly Interface: Features bi-directional RS 232 connectivity for seamless integration with a PC (Core i3 or higher).
• Compact Design: Boasts the world’s smallest footprint for a chemistry analyzer of its class, optimizing laboratory space.
• Durability & Reliability: Built with robust components for consistent performance and long-term operational stability.

Technical Specifications

• System Type: Standing Random Clinical Chemistry & Turbidimetry Analyzer
• Throughput: Up to 220 test/hour (base system); Up to 640 tests/hour (with optional ISE module)
• Sample Types: Serum, Plasma, CSF, Urine
• Sample Volume: 2-40 µl (adjustable in 1 µl steps)
• Sensors: Liquid Level Sensor, Crash Sensor
• STAT Analysis: Yes, available at any time
• Ion Measurement: Photometric tests for Na, K, Cl
• Calibration: Linear, Non-linear, Multi-point
• Sample Containers: Primary tubes (5 ml), Sample cups (2.5 ml)
• Photometry Wavelengths: 8 wavelengths (340, 405, 450, 510, 546, 578, 630, 670 nm) – Mono & Bichromatic
• Linearity & Resolution: Linearity (0-3.5 OD), Resolution (0.0001 OD)
• System Interface: Analyzer to PC: RS 232 bi-directional; PC Requirement: Core i3 or higher
• Power Source: AC 110/220V, 60/50 Hz; ~300 VA (excluding PC/printer/monitor)
• Dimensions (W x D x H): 60 cm x 104.7 cm x 113.4 cm
• Weight: Approximately 230 kg
