DiaSYS Full Auto Biochemistry Analyzer DIA-4400

DiaSYS Full Auto Biochemistry Analyzer DIA-4400 Overview

The DiaSYS Full Auto Biochemistry Analyzer DIA-4400 is a state-of-the-art, floor-standing clinical chemistry and turbidimetry analyzer engineered for high-throughput laboratory environments. This advanced system is meticulously designed to provide accurate and reliable biochemical analysis, making it an indispensable tool for diagnostic laboratories and healthcare facilities across Bangladesh. Its compact, world-smallest design for its class belies its powerful capabilities, offering exceptional performance and efficiency for a wide range of diagnostic tests.

DiaSYS Full Auto Biochemistry Analyzer DIA-4400 Key Features & Benefits

• High Throughput: Capable of performing up to 320 tests per hour, significantly enhancing laboratory workflow efficiency.
• Versatile Sample Handling: Accepts various sample types including Serum, Plasma, CSF, and Urine, offering broad diagnostic application.
• Precise Sample Volume Control: Adjustable sample volume from 2-40 µL in 1 µL increments ensures optimal reagent usage and accuracy.
• Advanced Sensor Technology: Equipped with liquid level and crash sensors to prevent errors and protect the instrument.
• STAT Analysis Capability: Allows for the immediate loading of emergency samples without interrupting ongoing tests, crucial for critical patient care.
• Integrated Ion Measurement: Photometric tests for Na, K, and Cl provide essential electrolyte balance data.
• Flexible Calibration: Supports linear, non-linear, and multi-point calibration methods for maximum assay flexibility.
• Robust Photometry System: Features 8 wavelengths (340, 405, 450, 510, 546, 578, 630, and 670 nm) for both mono- and bichromatic measurements, ensuring broad spectral analysis capabilities.
• High Linearity & Resolution: Achieves excellent linearity up to 3.5 OD and a resolution of 0.0001 OD for precise quantitative results.
• User-Friendly Interface: Bi-directional RS 232 connectivity for seamless integration with laboratory information systems (LIS) or PCs (Core i3 or higher).
• Compact & Efficient Design: Despite its robust performance, it boasts a world-smallest footprint for its class, optimizing laboratory space.

Technical Specifications

• System Type: Floor-standing Random Clinical Chemistry & Turbidimetry Analyzer
• Throughput: Up to 320 tests/hour
• Sample Types: Serum, Plasma, CSF, Urine
• Sample Volume: 2-40 µL (step 1 µL)
• Sensors: Liquid level sensor & crash sensor
• STAT Analytic: Yes
• Ion Measurement: Photometric tests for Na, K, Cl
• Calibration: Linear, non-linear, multi-point
• Sample Tubes/Cups: Primary tubes (5ml) & sample cups (2.5 ml)
• Photometry Wavelengths: 340, 405, 450, 510, 546, 578, 630, 670 nm (mono & bichromatic)
• Linearity: 0-3.5 OD
• Resolution: 0.0001 OD
• System Interface: Analyzer to PC: RS 232 bi-directional connectivity
• PC Requirements: Core i3 or higher
• Power Source: AC 110/220V, 60/50 Hz; 300 VA (excluding PC/printer/monitor)
• Dimensions: 60 cm (W) x 104.7 cm (D) x 113.4 cm (H)
• Weight: Approximately 230 kg
