ICUBIO iChem-535 Semi-auto Chemistry

ICUBIO iChem-535 Semi-auto Chemistry Overview

The ICUBIO iChem-535 Semi-auto Chemistry analyzer is a high-precision device designed for biochemical and chemical analysis in various research and laboratory settings. Its advanced features and capabilities make it an ideal choice for professionals seeking accurate and reliable results.

ICUBIO iChem-535 Semi-auto Chemistry Key Features & Benefits

• 7-inch Color LCD Touchscreen: Displays real-time curves and provides an intuitive user interface.
• 7 Wavelengths & 80 Test Items: Pre-programmed with 80 test items and 7 wavelength options for comprehensive analysis.
• Memory for 10,000 Sample Results: Stores up to 10,000 sample results for data management and analysis.
• Light Source Hibernate Function: Prolongs the lamp’s lifespan by reducing power consumption when not in use.
• 10 Incubators (Optional): Maintains a precise temperature of 37 ± 0.3°C for optimal sample conditions.
• Flow-Cell & Cuvette Mode: Offers flexibility in sample handling with both flow-cell and cuvette modes available.
• RS-232 Interface: Enables seamless connectivity to PCs for data transfer and analysis.

Technical Specifications

• Wavelength Precision: ±2nm, width ≤ 10nm
• Absorbance Range: 0~4.500 Abs
• Absorbance Precision: Outside 0.0001 Abs, inside 0.00001 Abs
• Carryover: < 1%
• Repeatability CV: < 1%
• Incubator: 37℃, 30℃, 25℃, and others, Precision: ±0.1℃
• Sample Volume: 0~3000ul (500ul recommended)
• Power Supply: 100~240VAC, 50~60Hz, 100VA
• Dimension: L340mm* W270mm*H160mm
• Net Weight: 5KG, Gross Weight: 10.5KG
