BIOELAB AS-280 Automated Clinical Chemistry Analyzer

BIOELAB AS-280 Automated Clinical Chemistry Analyzer: Precision Diagnostics for Modern Laboratories

The BIOELAB AS-280 Automated Clinical Chemistry Analyzer is a state-of-the-art, random-access diagnostic instrument engineered to deliver high-throughput, accurate, and reliable biochemical analysis. Designed for clinical laboratories of all sizes, this fully automated system streamlines workflows, enhances diagnostic precision, and ensures efficient patient care by processing a wide range of biochemical tests with exceptional speed and accuracy.

BIOELAB AS-280 Automated Clinical Chemistry Analyzer Key Features

• Exceptional Throughput: Achieves a constant speed of 200 tests per hour, supporting both single and double reagent assays without compromising efficiency.
• Extensive Capacity: Features a generous 80 reagent positions (40 for R1 & 40 for R2) and 40 sample positions, enabling continuous operation and reduced turnaround times.
• Advanced Cooling System: Equipped with a non-stop cooling system utilizing a Peltier pad, maintaining reagent temperatures consistently between 2℃ and 14℃ for 24 hours, ensuring reagent stability and test integrity.
• User-Centric Software: Boasts a simple, intuitive, and user-friendly software interface designed for ease of operation and minimal training requirements.
• Automated Sample Handling: Incorporates automatic sample dilution capabilities (decrease, increase, normal) and sophisticated liquid surface detection for precise sample and reagent aspiration, minimizing carry-over and maximizing accuracy.
• Intelligent Quality Control: Features automated reaction result checking, calibration verification, and a comprehensive warning alarm log. Supports advanced quality control applications including Westgard rules, L-T plots, and cumulative QC data.
• Flexible Calibration: Offers robust calibration options including linear, non-linear, and multi-point calibration up to 8 points, catering to diverse assay requirements.
• Robust Construction: Designed with precision sampling probes featuring collision protection, automatic depth adjustment, and dedicated internal/external washing mechanisms to ensure longevity and consistent performance.
• Optimized Mixing: Utilizes a Teflon-coated mixer with a standardized procedure for superior mixing effects, significantly reducing the risk of carry-over.
• Versatile Sample Compatibility: Accepts various sample containers including micro cups, standard test tubes, and blood collection tubes (Φ12-13mm × 25-100mm).

Technical Specifications

• Type: Random Access, Open Reagent System (Locked Reagent Optional)
• Test Speed: 200 tests/hour (Constant)
• Test Principles: Colorimetric Method, Turbidimetry
• Test Methods: 1-Point End, 2-Point End, Fixed Time, Kinetics
• Calibration Types: Linear & Non-linear, Multi-point (up to 8 points)
• Sample Tray Capacity: 40 Positions
• Sample Volume: 2-30 µL (0.1 µL increments)
• Sample Probe Features: Liquid Surface Detection, Timely Liquid Volume Tracking, Collision Avoidance, Multifunctional Precision Sampling
• Reagent Tray Capacity: 80 Positions (40 x R1, 40 x R2)
• Reagent Cooling: Non-stop 2℃-14℃ (Peltier Pad)
• Reagent Volume: 20-300 µL (1 µL increments)
• Reagent Probe Features: Liquid Surface Detection, Timely Liquid Volume Tracking, Internal & External Mirror Polish, Probe Washing
• Reaction Tray Capacity: 44 Reaction Cuvettes
• Reaction Volume: As Low as 150 µL
• Reaction Temperature: Stable 37℃ ±0.1℃
• Washing System: 3×4 Steps Automatic Washing
• Software: User-Friendly Interface, Automated Dilution, Result & Calibration Checking, Alarm Log
• Quality Control: Westgard Rules, L-T Plot, Cumulative
• Optional Features: Sample Barcode Reader
