Edan 3D/4D Acclarix Lx25 Diagnostic Ultrasound System

Edan 3D/4D Acclarix Lx25 Diagnostic Ultrasound System Overview

The Edan 3D/4D Acclarix Lx25 Diagnostic Ultrasound System is a state-of-the-art medical imaging solution engineered to deliver exceptional diagnostic accuracy and workflow efficiency. Designed for comprehensive clinical applications, this advanced system integrates cutting-edge technology with an intuitive user interface, empowering healthcare professionals in primary care and beyond for precise prevention and early detection. Its robust capabilities enrich diagnostic insights, significantly enhancing clinical value and patient outcomes.

Edan 3D/4D Acclarix Lx25 Diagnostic Ultrasound System Key Features

• Versatile Transducer Support: Features 5 transducer sockets, catering to a wide array of comprehensive clinical needs and ensuring adaptability across various examinations.
• Ergonomic Design: Boasts an integrated, user-friendly interface with an ergonomically designed height adjustment mechanism for optimal user comfort during extended use.
• Uninterrupted Operation: Equipped with built-in batteries, providing reliable backup power and enabling ultra-long continuous scanning times without interruption.
• Superior Visual Clarity: A 21.5-inch high-resolution LCD medical monitor offers multi-dimensional viewing angles for detailed image assessment, complemented by a 14-inch high-sensitivity touch screen for intuitive, fingertip control.
• Intelligent Workflow Enhancements: Includes one-key optimizations for B/Color/PW modes, automatic PW trace for rapid measurements, and high-capacity storage with easy USB transfer.
• Advanced Gesture Control: The innovative ‘eTouch’ feature allows for efficient ‘Swipe’ gesture control, streamlining operation.
• User-Centric Learning: ‘eLearn’ provides user-friendly tutorial software for quick proficiency and mastery of the system’s functions.
• Detachable Gel Warmer: A humanized, detachable gel warmer ensures patient comfort during examinations.

Technical Specifications

• Monitor: 21.5-inch high-resolution TFT LCD monitor with adjustable tilt (30° upward, 90° downward) and swivel (+/-90°), offering wide viewing angles (89° in all directions). Includes built-in stereo speakers and adjustable brightness/contrast.
• Touch Screen: 14-inch high-sensitivity touch screen with gesture control, user-configurable UI, and support for QWERTY keyboard input. Brightness is adjustable.
• Transducer Ports: 3 active ports with 5 holders, including one dedicated for endocavity transducers. Supports electronic transducer selection.
• Control Panel: Features interactive backlighting, tactile feedback hard keys, programmable store keys, a physical trackball, 8-segment TGC sliders, and a wireless keyboard.
• Connectivity: Supports Verify SCP, Static image store SCU, Ultrasound multi-image store SCU, four levels of compression, and multiple data transfer options including removable media and in-progress/auto/manual background network storage. Includes 6 USB Ports (4x USB 2.0, 2x USB 3.0). Video output options include VGA, DVI, S-video (PAL/NTSC), and Ethernet. Wi-Fi enabled.
• DICOM Compliance: Fully compliant with DICOM Modality Worklist, DICOM Structured Report (OB, GYN, Cardiac, Vascular), DICOM store to multiple networks, Non-DICOM network transfer (FTP in background), and DICOM Print. Supports DICOM MPPS.
• Imaging Storage: 120 GB SSD with storage for over 400,000 lossless single frames. Supports lossless, high, mid, and low compression for static images and clips.
• Image Processing: Advanced suite including Tissue Adaptive Imaging (TAI), Adaptive Doppler, Frequency Compounding, Adaptive Spatial Compounding, Harmonic Imaging, Adaptive Speckle Reduction Imaging (eSRI), Spectrum Enhancement, and Auto Optimization for B, Color, and PW modes. Digital Multi-Beam Beamforming with up to 2,949,120 digital channels. Trapezoid Imaging for linear transducers, B Steer, Pan Zoom, Spot Zoom, Full screen imaging, and Needle Enhancement Visualization Imaging.
• 3D/4D Imaging: Supports 4D and Static 3D acquisition modes with Volume Rendering, PRs, and Multi-Slice visualization. Features adjustable VOI, curve cut planes, and various render modes (Surface, MIP, X-Ray). Includes 3D Clip, Cut tools (trace, box, erase), undo/redo functionality, and display formats like Single 3D, Dual (A-plane + 3D), and Quad (A/B/C Planes + 3D). Parameters for 3D include Threshold, Smooth, Brightness, Contrast, and Tint. ‘eFace’ for automatic face rendering. Supports saving and editing volume data sets.
• Post-Processing: Comprehensive tools for B Mode (gain, TGC, zoom, dynamic range, eSRI, colorize, map), M Mode (gain, TGC, dynamic range, colorize, map), Color Mode (zoom, color map, invert), and PW/CW (gain, dynamic range, colorize, map, baseline, angle, invert). Supports exam review, image export (BMP, AVI, DCM), exam import/export, and annotation tools including body marks and measurements.
• Biopsy Guide: Optional, available for enhanced procedural guidance.
