BT 400 Infant phototherapy lamp – Bistos

BT 400 Infant Phototherapy Lamp – Bistos: Advanced Neonatal Jaundice Treatment

The Bistos BT-400 Infant Phototherapy Lamp is a state-of-the-art medical device engineered for the effective treatment of neonatal jaundice. Utilizing advanced blue LED technology, this lamp offers a superior, safer, and more efficient alternative to traditional phototherapy methods, ensuring optimal care for newborns during a critical phase of their development. Its design prioritizes patient comfort, caregiver ease of use, and clinical efficacy.

BT 400 Infant Phototherapy Lamp – Bistos Key Features

• Extended Lifespan & Efficiency: Features a blue LED light source with an operational lifespan of up to 20,000 hours, significantly outlasting conventional fluorescent or halogen lamps.
• Reduced Heat Side Effects: Engineered for minimal heat emission, ensuring a more comfortable environment for the infant and reducing the risk of overheating. Heat output is less than 10°C warmer than ambient over 6 hours at 40 cm.
• Adjustable Intensity & Speed: Offers two adjustable intensity levels (Low: 20-70 µW/cm²/nm; High: 40-100 µW/cm²/nm) to tailor treatment to individual infant needs, with adjustable speed settings for enhanced control.
• Precise Treatment Area: Provides an effective illumination area of 40 x 20 cm, ensuring comprehensive coverage for treatment.
• Intuitive LCD Display: Features a clear LCD screen that displays operating time, total accumulated hours, and timer settings, facilitating accurate monitoring and record-keeping.
• User-Friendly Operation: Designed with a compact size, simple interface, and adjustable head movement for ease of positioning and optimal clinical application.
• Integrated Timer: A versatile timer function allows for treatment durations ranging from 30 minutes to 999 hours.
• Safety Considerations: While optional protective eyeshades are recommended to shield the infant’s eyes from unnecessary light exposure, the lamp itself is designed with infant safety in mind.

Technical Specifications

• Brand: Bistos
• Model: BT-400
• Light Source: Blue LEDs
• Wavelength: Peak between 450 nm and 475 nm
• Intensity: 20 ~ 100 µW/cm²/nm at 40 cm
• Intensity Variation (over 6 hours): ± 10% (within the illumination area)
• Effective Surface Area: 40 x 20 cm
• Low Intensity Setting: 20 ~ 70 µW/cm²/nm ± 10%
• High Intensity Setting: 40 ~ 100 µW/cm²/nm ± 10%
• Timer Range: 30 min. ~ 999 hours
• Heat Output: Over 6 hours < 10 °C warmer than ambient (at 40 cm)
• Display: LCD (Operating Hour, Total Hour, Timer, Adjustable Intensity)
• Installation Options: Mobile Cart, Pole Mounted, Incubator
• Input Power: 100-240 VAC, 50/60 Hz
• Power Consumption: 70 VA
• Leakage Current: < 100 µA
• Audible Noise: < 60 dB
• Dimensions: 34 x 21 x 7.5 CM
