BIOMAX 20 Hole Auto ESR Analyzer

BIOMAX 20 Hole Auto ESR Analyzer: Precision Diagnostics for Bangladeshi Healthcare

The BIOMAX 20 Hole Auto ESR Analyzer is a state-of-the-art, semi-automatic diagnostic instrument engineered to deliver accurate and efficient Erythrocyte Sedimentation Rate (ESR) testing. Designed for clinical laboratories and healthcare facilities across Bangladesh, this analyzer automates the tedious process of ESR measurement, ensuring reliable results and enhanced workflow productivity. Its advanced infrared transmitter-receiver system allows for simultaneous monitoring of up to 20 samples, making it an indispensable tool for high-volume diagnostic needs.

BIOMAX 20 Hole Auto ESR Analyzer: Key Features & Benefits

• Simultaneous Multi-Sample Analysis: Accommodates 20 test tubes, enabling concurrent testing for increased throughput and reduced turnaround time.
• High Precision Measurement: Utilizes an infrared transmitter-receiver system with a resolution of 0.2mm vertical distance per reading, ensuring exceptional accuracy in monitoring erythrocyte sedimentation.
• Automated Operation: Initiates measurement automatically upon insertion of test tubes (with valid barcode entry), simplifying the testing procedure.
• Intelligent Blood Level Detection: Automatically judges and confirms the blood height within the acceptable range (50mm to 64mm), preventing errors and ensuring test integrity.
• Fast Throughput: Achieves a maximum mensuration speed of 40 pieces per hour, significantly boosting laboratory efficiency.
• Integrated Printer: Features a built-in printer for immediate, hard-copy results, facilitating easy documentation and reporting.
• Automatic Temperature Conversion: Compensates for temperature variations with an automatic conversion at 18℃, ensuring consistent accuracy across different environmental conditions.
• User-Friendly Interface: Designed for ease of operation, minimizing the learning curve for laboratory personnel.
• Data Management: Equipped with USB input for data transfer and a memory capacity of 260 results for efficient record-keeping.

Technical Specifications

• Model: BIOMAX 20 Hole Auto ESR Analyzer
• Worker Mode: Semi-automatic
• Capacity: 20 test tubes
• Measuring Time: 30/60 Minutes per batch
• Maximum Mensuration Speed: 40 pcs/h
• Mechanical/Optical Exactness of Detection: +/- 0.1mm
• Reproducibility of Analysis: <3%
• Reading Quality Among Every Channel: C.V. <6%
• Memory Capacity: 260 results
• Input: USB
• Printer Type: Built-in printer
• Automatic Temperature Conversion: 18℃
• Blood Height Range: 50mm – 64mm
